Location： Products > Industry and electricity > Deluxe Vehicle Power Pedestal
DJG-DPP
EEMAC/NEMA Enclosure Type 3R
■ Model # DJG-DPP mini RV pedestal■ EEMAC 3R enclosure
■ Compact architecturally pleasing design
■ HD galvanized construction for Body & hood
■ Cover has ASA 61grey powder paint finish
■ 305mm high x 203mm wide x 127mm deep body
■ Devices and WP covers are side mounted
■ Heavy duty molded case circuit breakers are 10kA
■ Breakers are accessible from underside
■ Ideal for loop feeding systems reducing installation costs
■ Prewired at factory
■ Will accept up to two 50.8mm connectors in bottom
■ Optional: Model #2E-MVR-ST
■ Heavy duty galvanized stake for mounting
