DJFP-100/125 Square Meter Sockets
Features
■ Standard meter sockets are manufactured from 1.2-1.5MM galvanized steel with a baked gray powder polyester paint finish to improve corrosion resistance■ These meter socket suitable for single Phase, service voltage 600Vac Max
■ Ample gutter space for easy wiring
■ Convenient knockouts in side back and bottom
■ Lay in type terminals with pressure plates for easy connections
■ Meter sockets are designed to accept conduit hubs from 1'' to 2-1/2'' size
Specification
| Type No. | Description | Outline Dimensions | ||
| H | W | D | ||
| DJFP-100A/4J | 1 Phase, 100A,4 jaw, ring type | 226.5 | 194 | 111 |
| DJFP-125A/4J | 1 Phase, 125A,4 jaw, ringless type | 324.2 | 219 | 116.2 |
| DJFP-125A/5J | 1 Phase, 125A,5 jaw, ringless type | 324.2 | 219 | 116.2 |
| Customize |
more size to be request to the clients, please email:happy@henghao.hk, export@henghao.hk |
|||
More technical information and dimensions, to the top right corner of the page to download
